Understanding Modulation Effects

The world of guitar (and synth, and bass…) modulation effects overwhelmed me at first, but I’ve learned that most pedals and plugins are based around just a couple of ideas.

Time-based effectsFilter-based effects
Base versionChorusPhaser
VariationsFlange (chorus with feedback)

Vibrato (chorus with no dry signal)
Uni-Vibe or “Vibe” (phaser
with mis-matched filters)

Time-based effects are created by 1) copying the input signal, 2) delaying the copy by a small amount (a few milliseconds), 3) automatically changing the delay time (say, from 27 ms to 33 ms and back), and then 4) mixing the input (or “dry,” or “not delayed) and delayed signals together (typically at a 50:50 ratio). The resulting sound is a pseudo-doubling effect with a bit of pitch going up and down, some frequencies of the input signal enhanced, and others diminished. Boom; basic chorus.

Flangers operate on the same principle, with shorter delay times and feedback in the delay signal path (just like a delay or echo pedal), resulting in a more pronounced effect. Flangers with knobs for feedback amount are often great modulation pedals because they can cover a lot of territory from subtle near-chorus to crazy flying saucer flange.

Vibrato – the signal’s pitch moving up and down – is just chorus without the dry signal. When the delay time is getting shorter, the pitch is going up, and vice versa. You can test this out on your own with any delay pedal; play a sustaining note or chord, then turn the delay time faster or slower. You’ll hear the pitch of the delayed signal go up or down accordingly.

Filter-based effects

Filter-based effects are created by 1) copying the input signal (noticing a pattern here?), 2) sending the copy through a series of all-pass filters, 3) automatically changing the center frequencies of the all-pass filters* (say, from 500 Hz to 2000 Hz and back), and then 4) mixing the input (or “dry,” or “not all-passed”) and filtered signals back together. The resulting sound has a series of mid frequency cuts that move up and down. We’re phasing!

* Optional sidebar – Filters are usually used to boost or cut certain frequencies in a signal. All-pass filters don’t boost or cut any frequency, but they delay the frequencies around the center frequency a tiny amount. If an all-pass filter’s center frequency is 1000 Hz the frequencies around 1000 Hz are delayed the most (still a tiny amount), the frequencies around 500 and 2000 Hz are delayed less, the frequencies around 250 and 4000 Hz are delayed less (almost none), and so on.

The all-pass filters in Uni-Vibe or “Vibe” effects are purposefully mis-matched. This was originally done to mimic the sound of a rotary speaker cabinet. Most people don’t consider it a particularly accurate re-creation of that sound, but it has a cool sound of its own (I adore the “Vibe”-type sounds of my Wilson Effects Haze! There’s even an unreleased Mars Lights song named after that pedal).

Other modulation effects

Amplitude (volume) modulation – tremolo – is the other main type of modulation effect. This is simply the volume of a signal going up and down regularly, like a couple of times per second.

Some Fender amps incorrectly call this type of built-in amplitude modulation “vibrato” instead of tremolo.

Real rotary speaker cabinets and re-creations of them have much more complex modulation going on than a chorus or phaser. There’s pitch modulation, phase modulation, amp distortion, speaker breakup, and more, and these changes interact with each other in complex ways. Rotary speaker cabinets are amazing.

Vibrato and “Vibe”-style effects are often and understandably confused for each other due to the similar names. However, they are generated by different types of circuits and have different sounds.

Wah and auto-wah effects are also filter-based, but a different type of filter (resonant bandpass or lowpass) than phasers (all-pass). Wah effects are not usually considered modulation because the player controls the change in sound, rather than it being done automatically by the circuit.

DS-1 Fleet

For my own future reference, here’s the status of my DS-1s. I switched the battery covers and knobs to get them back to “stock.”

OG “Dark Satellites” and Lab

On the left is my first pedal ever, circa 2001-02 for use in No Front with a borrowed double cut Les Paul Jr. and AC30. Cole performed the Casper Electronics mod and did the battery cover art around 2014-15, I did further Casper-related mods in 2016, and recently I put a tone stack mod on a toggle hidden in the battery compartment. This unit will live on the synth minirig board.

On the right is the “DS-1 lab,” my research platform and repository of all of my favorite adjustments, from 2016. It’s a studio piece for guitar, mostly.

Pedal work

Been working on pedals for the past few weeks while I write Fight Songs lyrics.

From top left: V4 MV, DS-1 mods, 404 M 2 ST, R2-T2

These are all one-off builds for my own use.

  • V4 MV – Passive master volume control for my Ampeg V4 amplifier. Ampeg used to sell these as an accessory but they’re dead simple to make; a single potentiometer wired as a variable resistor. The amp is incredibly loud so this will help bring it partially under control
  • DS-1 mods. This pedal is literally my first, from around 2002 (except for the battery compartment cover donated from the “DS-1 lab” unit). At my request Cole modded it years ago with the Casper Electronics gated feedback/oscillation mod. I added my flat + LPF tone stack mod, tucked away on a toggle in the battery compartment
  • 404 M 2 ST – A passive mono-to-stereo passive pan box mostly designed for use with my SP-404 sampler. The 404 can record in mono or stereo, and has stereo effects, but doesn’t have any type of simple pan control to move things around in the stereo image. With this I can pan stuff as it’s being sampled
  • R2-T2 – Breakout expression box for the Pigtronix Rototron rotary speaker simulator (which mostly lives with my Roland VK-1 organ). The footswitch and toggle engage the Brake function. The knob can be plugged into either the Low or High Rotor Control to defeat the on-board Speed control for that “rotor.” If it’s reminiscent of anyone’s favorite droid, well, that’s a happy coincidence
Daylight Express Deluxe 1776 Effects ‘Plex Delay

Then, I made two of these (one went to Drew). It’s a dual delay based on the 1776 Effects Multiplex Jr. with custom additions and modifications. I’m not aware of any other pedal on Earth that does what this does.

There are two big things left on this summer’s soldering list: rebuilding my AX-60 synthesizer’s power supply (already under way), and fixing whatever’s wrong with Scottie’s Rhodes amp (I suspect just a bad joint or hardware connection). Then I suppose I’ll turn to the breadboard and design something. No shortage of ideas.

Night Mode “Nobody Lived” Out Now On Completely Gone Recordings

For the first time, we’re releasing music on another label! Night Mode’s new album Nobody Lived is out now courtesy of Completely Gone Recordings.

Nobody Lived is the live set Drew and I were preparing in March 2020, as the pandemic loomed. The show at Records with Merritt was ultimately cancelled. From the liner notes, the email that got it started –

“like 1:00 sunday? my idea for a piece is building up a volca bass sequence in the C dim scale (or any diminished scale, but C is easyish) and tearing it back down to noise/sub freqs. then i was thinking the paraphonic ms20 patch as an accompaniment to something of yours.”

These sessions also yielded the tracks “No One,” which appeared on Completely Gone Recordings’ Volume VIII compilation, and “No Two” (Silber Records Droneuary 2021).

“Fight Songs” Guitars Are Done!

I finished guitars for Fight Songs last week, I think Friday night. The last few tracks were Motown-inspired guitar DIs using the setup below.

Something old, something new, something I made, something from Radio Shack. That’s how it goes, right?

Signal path, from the right:

Pigtronix Philosopher’s Tone Germanium Gold Micro – Quite a mouthful for this little optical compressor. Picked it up used on a lark based on how much I’ve enjoyed the DOD 280 reissue, and the added blend and grit controls are nice additions.

Fulltone GT-500 – Haven’t used this in quite a while. As I was recording I decided I wanted a kind of cocked wah sound, but an actual wah was too much. The inductor-based mids control on the distortion side of the 500 was perfect cranked all the way up. Only used this for the EQ, it’s not doing any distortion.

Mr. Furious Audio Falcon Heavy Drive – Getting some 2nd harmonic saturation here, using the bridged-T mid notch, and shelving off some low end.

Radio Shack DI – This is a cheap transformer-based DI that works great for the vintage, bandpassed sound I wanted.

Next I’m going to take some time to get the mixes into rough shape, write lyrics (about half the songs are already done, maybe more than half), and do a bunch of pedal projects before I dive back into recording vocals and miscellaneous percussion. Then keys, backing vocals, guest artists’ parts, and… we’ll just about have a record.

New Ampeg V-4 Day

I impulse-bought an Ampeg V-4 and matching speaker cabinet this week.

The Beast

Price was bordering too good to be true, but it’s in pretty great shape considering it was built somewhere between 1972 and ’75.

Unfortunately the serial can’t be used to give a precise build date. The potentiometers, only viewable by opening up the amp, would.

I’ve hoped to run across a deal on an old Sunn or Hiwatt to pair with my Sunn 2×12 cabinet for a long time, but it was always a long shot. This isn’t quite the same sound, but it is in the ballpark of big, loud cleans and classic drive tones. I’m considering it an upgrade to both that Sunn cab and my Music Man Sixty-Five and its 1×15 ported cab, which will be looking for new homes soon.

Cool badge

This is a huge amp, physically and sonically. I tested it outside, and it was rearranging my internal organs with the volume on about 3. The head and the cab each weigh something like 80 pounds. The output transformer is the biggest I’ve ever seen.

It needs a little TLC from a good tech and I won’t get to turn it up very often any time soon, but this is a super cool upgrade in the big clean and bass-friendly amp department and my first all-tube vintage amp. (The Music Man has a solid state preamp.)

Back In The (Soldering) Saddle

I haven’t done any meaningful soldering since making last summer’s Thereatari, but I’m getting ready to. The other day I modified my Caroline Guitar Company Meteore reverb.

I always liked (and haven’t changed!) the sound of this pedal, but I had a couple problems using it: the sweep of the reverb volume knob made it hard to dial in the amount of reverb I want, and the “Havoc” switch went to instant oscillating madness when the size, regeneration, and gain controls were above about halfway.

To address the first issue, I switched out the stock anti-logarithmic “C” taper potentiometer for a linear “B” taper. No change in sound, but more fine control over low and medium reverb volumes.

For the second, I put a potentiometer wired as a variable resistor in the “Havoc” switch feedback path. This is the new knob on the side of the pedal. At maximum, it gives the stock sounds. As it’s rolled back, it reduces the feedback when “Havoc” is engaged. This is great because I can set the reverb how I want, and still get a useable sound from the “Havoc” switch (instead of immediate blaring chaos… though it can still do that, too!).

Had no problems, other than cleaning off my iron’s tip, so it was a good warm-up for summer projects like a pair of semi-modular delays for Drew and I, my AX-60 power supply (finally), and maybe a short run of pedals (probably a transistor boost). We’ll see how far I get on that list.
